M2N32-SLI Deluxe Wireless Edition
ASUS M2N32-SLI Deluxe is the
first ASUS mainboard based on the NVIDIA nForce 590 SLI MCP chipset. This
chipset supports LInk Boost and Tritrium Technology. It supports 2 PCIe x16 with
SLI support at full x16,x16 speed. There is another 1 PCIe X4 slot supporting
PCIe x4 or x1 card. There are 1 x PCIe x1 slot and 2 x PCI 2.2 slots.
The NForce 590 SLI MCP supports 1 x IDE upto 2 UDMA 133/100/66/33 devices, 6
SATA II 3.0 Gb/s. It can run in RAID 0, 1, 0+1, 5 and JBOD configuration
spanning across SATA drives via the onboard Mediashield RAID controller. There
is an additional Sil 3132 SATA II controller which supports 1 internal SATA II
port and 1 external SATA II port. It supports RAID 0,1, and JBOD.
The board has Dual GbE featuring AI NET2 using MCP MAC with Marvell PHY (x2) It
supports teaming and Fail Over functions.
8 ch audio is supported using SoundMax ADI AD1998B codec. It supports jack
sensing, multi streaming, DTS connect etc. This wireless edition also supprot
Wi-Fi@Home USB wireless module for 802.11 b/g. 2 x 1394 ports and support up to
8 USB 2.0 ports on the standard edition 10 USB 2.0 ports supported on the
