Introduction of Shuttle XPC Glamor SN68PTG6 Deluxe Review
Bluetooth 7 Dec 2007

Introduction



With cheaper LCD TV sets and better quality HIFI components, the thought of having a media centre is always my dream. I have tried that before, using the older Shuttle XPC series but it just couldn't do the work with current LCD TV which are equipped with HDMI ports for HDCP encryption.

While I am no longer interested in watching SD movies, I have invested in a XBOX HD DVD player some time ago. I use it with my VISTA PC to watch HD movies that I buy online. Although it looks crisp clear, I am viewing it off a 20" which defeats the whole purpose of HD since it is shown on a small screen.

I do have a 42" LCD TV in my living room though connected with local telco's HD Pay tv system. I wouldn't want to bring my PC which is big and clumsy, blocking everyone's way just to watch one film!

The Shuttle XPC SN68PTG6 Deluxe solved all these problems. Based on the NV 7050-630a chipset, it supports the X2, A64 and Sempron CPUs. Just like the earlier MCP68 boards we reviewed before, this board supports 4GB of DDR2-800. It comes with GbE, Firewire, 6 USB, eSATA, 8 ch audio, HDMI(with HDCP), WIFI and Bluetooth. On top of that, it has a Finger Recognition system and a USB Speed Link feature. The Finger recognition system allows you to use it for login authentication (VISTA), opening of encrypted files and logging in to websites without remembering passwords.

Specs

Technical details:
Shuttle XPC Glamor Series

* NVIDIA® GeForce 7050PV/630a
* Supports AMD® Athlon™64 X2, Athlon™64 and Sempron™ series, Hyper Transport 1.0
* Max. 4 GB Dual Channel DDR2 800 (OC to 1066 MHz)
* NVIDIA® GeForce7050PV with HDMI/HDCP
* 8-Channel HD Audio with Dolby® Digital Live! and DTS® Connect
* 1x PCI-E X16, 1x PCI
* Gigabit LAN
* 2x Firewire, 6x USB 2.0
* 2x SATA2, 2x eSATA
* Bluetooth 2.0+EDR (Deluxe model only)
* 802.11b/g WiFi (Deluxe model only)
* USB Speed-Link Technology (Deluxe model only)
* Fingerprint Recognition Security (Deluxe model only)
* 250-Watt power supply / 300-Watt power supply (Deluxe model only)
* 310(L) x 200(W) x 185(H) mm


Discuss in Forum
