NFORCE 570 SLIT-A NF 570 SLI Intel Edition Conroe Mainboard Review Intro 1/5
Bluetooth 29 Aug 2006
|
Pricing
of
ECS NFORCE 570 SLIT-A
>>> |
|
Introduction
ECS NFORCE 570 SLIT-A
V5.1 is the
updated version that supports the new Conroe 1066FSB processors. Based on the NF
570 SLI chipsets which comes in a duo NF4 SLI SPP north bridge + MCP 430
southbridge chipset.
This mainboard supports LGA775 socket
for latest Intel Core 2 Duo / Pentium D / Pentium 4 / Celeron D processor FSB
1066/800/533 MHz. It supports Dual-channel DDR2 memory architecture with 4 x
240-pin DDR2 DIMM socket support up to 16GB. Memory supported is DDR2 533/667
DDR SDRAM.
The board comes with 2 PCIe x 8 slots. When in SLI mode, it will run in Dual 8x
mode (single PCI-E is x8 mode). There are two other PCIe x 1 and 3 PCI slots.
The south bridge supports 4 x Ultra
DMA133/100/66 devices, 4 x Serial ATA devices and can be configured to run in
RAID0, RAID1, RAID0+1, RAID5 configuration. There is also 8 ch hd audio using
the Realtek ALC883 codec. Built on board is a GbE using Marvell 88E1116
controller.
The board we have does not come with the
optional Realtek RTL8100C 10/100 Mbps Fast Ethernet Controller and IEEE 1394a
VIA 6307 support 2 x IEEE1394a ports
Specification
CPU LGA775 socket for latest Intel Core 2
Duo / Pentium D / Pentium 4 / Celeron D processor
FSB 1066/800/533 MHz
Support Hyper-Threading Technology
CHIPSET North Bridge: NVIDIA C19XE
South Bridge: NVIDIA MCP51
MEMORY Dual-channel DDR2 memory architecture
4 x 240-pin DDR2 DIMM socket support up to 16GB
Support DDR2 533/667 DDR SDRAM
EXPANSION SLOT 2 x PCI Express x16 slot (SLI mode: x8+x8, single PCI-E
is x8 mode)
2 x PCI Express x16 slot ( SLI mode: x8, x8 )
2 x PCI Express x1 slots
3 x PCI slots
STORAGE Supported by NVIDIA MCP51
-- 4 x Ultra DMA133/100/66 devices
-- 4 x Serial ATA devices
RAID0, RAID1, RAID0+1, RAID5 configuration
IEEE 1394a (optional) VIA 6307 support 2 x IEEE1394a ports
AUDIO Realtek ALC883 8-channel audio CODEC
LAN Marvell 88E1116 Gigabit LAN controller
Realtek RTL8100C 10/100 Mbps Fast Ethernet Controller(optional)
REAR PANEL I/O 1 x PS/2 keyboard & PS/2
mouse connectors
4 x USB ports
1 x RJ45 LAN connector
1 x Serial port (COM1)
1 x Audio port (Line-in, Line-out, Mic-in)
2 x Digital SPDIF (Optical & Coaxial) out
1 x Parallel port (LPT1)
INTERNAL I/O CONNECTORS & HEADERS 1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V connector
1 x FDD connector supports two 360K~2.88MB FDDs
1 x Auxiliary 4-pin +12V connector
1 x IrDA for SIR header
1 x Speaker header
2 x IDE connectors
4 x Serial ATA connectors
2 x USB 2.0 headers support additional 4 USB Ports
1 x Front panel switch/LED header
1 x Front panel audio header
CD in header
CPUFAN/NBFAN/SYSFANx2 connectors
SYSTEM BIOS AMI BIOS with 4Mb Flash ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Supports ACPI revision 1.0 specification
FORM FACTOR ATX Size 305mm*244mm
