ULi M1575
ULi M1575 is a highly integrated PCI
ExpressTM South Bridge that features advanced core technologies designed for
desktop and mobile computing applications. This PCIe based
South Bridge can be paired with ATi RS482 North bridge (with integrated video)
to deliver high performance HTPC systems.
With NVIDIA's invasion
into the integrated market, ATi boards can be paired up with the advance M1575
South Bridge to deliver amazing performance at a low cost. The ULI M1575 South
Bridge is one of them which offers competiting feature set to the MCP series
or even the single NF4 sinle chipset.
In this review, we will be
comparing the system performance of a RS482+M1575 ref board with existing
solutions out in the market. We will also take a look at integrated graphics
performance of RS482, M1575's USB and SATA II performance in Normal, RAID 0
and RAID 1 mode. Below is a detail specs of the M1575 south bridge.
Utilizing the evolutionary PCI ExpressTM bus architecture, M1575 offers system
manufacturers with unprecedented design-flexibility. It can be connected to
other PCI ExpressTM North Bridge or Switch via the built-in PCI ExpressTM x4
link. With the M1575 configured as an endpoint, a PCI Express™ add-in card
with M1575 on-board can easily empower any system with all the latest advanced
I/O features such as SATA-3Gbps, HD Audio, 8-port USB 2.0 host controller,
10/100 802.3x MAC, and soft-modem interface etc.
Because of the pin-to-pin compatibility to its predecessor M1573, M1575 is a
near direct drop-in to the existing motherboards designed. As such, effort
from the motherboard manufacturers to upgrade both the features and the
performance of their existing design are minimized.
Designed with advanced storage capabilities, the M1575 features unique support
of up to 4-ports AHCI based SATA 3Gbps with NCQ (Native Command Queuing) and
two ATA-133 as well as supports RAID 0, RAID 1, RAID 0+1, RAID 5, and JBOD
capabilities to provide highly efficient disk management and enhanced overall
storage performance.
Incorporating the ULiˇ¦s proven power management technology, ULi M1575 is the
paramount solution of choice for the increasingly energy efficient mobile PCs
and CE devices which need to support variety of multimedia intensive
Feature
High Integration South Bridge
- Integrated with Audio, HSP Modem, LAN,
USB, and IDE, M1575 is a high integration bridge between PCI Express, PCI
and Peripheral Buses for Desktop and Notebook Systems.
PCI Express Interface
- Low-overhead, low-latency communications
- Comprehend different data types and
ordering rules
- Power Management
PCI Interface
- Supports PCI Master and Slave Interface
- PCI spec. 2.3 compliant
- PCI Power Management Interface spec. 1.1
compliant
RAID Support
- Supports RAID 0, 1, 0+1, 5, JBOD
ports PCI Master and Slave Interface
Serial ATA Host Controller
- Supports SATA II at 3 Gb/s data rate
Enhanced DMA Controller
- Provides 7 Programmable Channels, 4 for
8-bit
Interrupt Controller
- Provides 14 Interrupt Channels
- Independent Programmable Level/Edge
Triggered Channels
- Integrated IO-APIC capability\
- Counter/Timers
- Provides 8254 Compatible Timers for System
- Timer, Refresh Request, and Speaker Output
Use
Serialized IRQ Supported
- Quiet/Continuous Mode
- Programmable (Default 21) IRQ/DATA Frames
Built-in Real Time Clock
- Common calendar year with leap year
compensation
- Binary or BCD data representation
- 12/24 hour mode
- Daylight saving time option
PMU Features
- Full Support for ACPI and OS Directed
Power Management
- Full Support for Instantly Available PC
feature
- CPU SMM Legacy Mode and SMI Feature
support
- Full Support of Clock Control Functions
- Supports I/O Trap for I/O Restart Feature
USB Interface
- One EHCI USB 2.0 and three OHCI USB 1.1
- Host Controllers for supporting up to
eight USB ports
Low Pin Count (LPC Rev1.1) Interface
- Supports LPC interface for legacy devices
- Supports 2 Master/DMA devices
- Supports firmware memory cycles with up to
16 byte read
Audio System
- Intel HD Audio compliant: enable DVD
audio, streaming video, Internet phone communications as well as auto
switching and detection of audio devices
- Fully Plug-and-Play PCI controller and
software
HD Audio Controller
- Microsoft Universal Audio Architecture
(UAA) compliant
- 6 generic output stream DMA Engines
- 5 generic input stream DMA Engines
- CORB/RIRB support
- Immediate command/response interface
support
Software Modem Interface
Provides AC'97 2.3 compliant digital
controller interface for third parties (such as the AMC Codec's vendor) to
enable the software modem solution.
1/10/100 Mb/s Fast Ethernet MAC
- Provides 1/10/100 Mbps Medium Access
Control (MAC) controller for the best solution of the phone-line/Ethernet
LAN connectivity
- Compliant with IEEE 802.3u 100BASE-TX,
IEEE 802.3 10BASE-T standard
628-Ball (31mmx 31mm) BGA Package
