Introduction
Do you ever
have problems connecting your PC to your wireless router that resides in another
room of your house? Do you get bad transmissions or worried that your network
gets tapped by other wireless users next door?
Aztech Homeplug HL108E puts and end to all these worries. You
no longer need to lay unsightly ethernet cables across the main hall or from 1st
floor to 2nd floor. Homeplug HL108E converts your existing Power Line that is
already laid to be used as the "ethernet cable".
Although this is not a new technology, it has been quite a
challenge to reached the theoritical levels of 100Mbps. HL108E improves on its
previous generation and is now rated at 200Mbps.
With more and more broadband users going for IPTV services
e.g. Singtel Mio TV which delivers through ethernet, HL108E comes in handy as
there are bound to be power plugs near your AV equipment. Thus, you not longer
need to lay unsightly cables or use WIFI thatresults in drop packets due to the
weak WiFi Signal.
Before we show you our tests on the next page. let's
take a look at the specifications below.
PRODUCT
SPECIFICATIONS
|
|
 |
HomePlug AV 1.0
specification, IEEE 802.3 10/100 Ethernet (100Mbps) and IEEE 802.3u Fast
Ethernet Compliant |
|
10/100 Mbps AutoMDI/MDIx
Support |
|
Co-exists with existing
14Mbps HomePlug 1.0 and 85Mbps Turbo HomePlug 1.0. (NOT backward
compatible to 14Mbps and 85Mbps) |
|
|
|
|
OFDM 1024/256/64/16/8 QAM,
QPSK, BPSK and ROBO Modulation Scheme |
|
|
|
|
2Mhz to 28Mhz band |
|
|
|
|
TDMA channel access with
Contention–Free and Contention-Based (CSMA/CA) period |
|
Channel Adaptation ensures
that signal integrity is maintained even under harsh noise environment |
|
Four Level prioritized
random access method based on contention access and multi-segment |
|
ToS and CoS Packet
Classifier |
|
Supports IGMP managed
multicast session |
|
|
|
|
128-bit AES Encryption with
key management for secure powerline communications (Utilise Windows
98SE, 2000, ME, XP to enable encryption) |
|
|
|
|
Intellon INT6000 Integrated
Single-chip Powerline Network Transceiver |
|
|
|
|
OS Independent with TCP/IP
protocol installed |
|
|
|
|
Switch Mode 100V-240V
Supply for Europe/UK/US/Australia plugs |
|
|
|
|
1 x Power LED |
|
1 x Powerline Link/Activity
Status LED |
|
1 x Ethernet Link/Activity
Status LED |
|
|
|
|
1 x Electrical Power plugs |
|
1 x RJ45 for 10/100
Ethernet (AutoMDI/MDI-X) |
|
|
|
|
Operating : |
0o to 40 o Celsius |
|
|
32 o to 104 o Fahrenheit |
|
Non-Operating :
|
-25 o to 70 o Celsius |
|
|
-13 o to 158 o Fahrenheit |
|
|
|
|
Operating : 30% to 80%
Relative Humidity (Non-Condensing) |
|
Non-Operating : 30% to 95%
Relative Humidity (Non-Condensing) |
|
