The Graphics Media Accelerator X3500 supports dual
VGA output support: HDMI/DVI-D and RGB
It also supports RGB with max. resolution 2048 x 1536@75Hz, s HDMI with max.
resolution 1920 x 1200@60Hz and DVI with max. resolution 1920 x 1200@60Hz.
A maximum shared memory of 384 MB. It also supports Microsoft® DirectX® 10,
OpenGL® 2.0, Pixel Shader 4.0. Currently the driver does not support DX10 as
yet. *The DirectX® 10 driver will be provided by the chipset vendor later.
This board supports the CPU LGA775 socket for Intel® Core™2 Quad / Core™2
Extreme / Core™2 Duo / Pentium® Extreme / Pentium® D / Pentium® 4 Processors,
compatible with Intel® 05B/05A/06 processors and support Intel® next generation
45nm Multi-Core CPU.
The board supports 4 x DIMM, max. 8GB, DDR2 800 /
667 MHz, non-ECC, un-buffered memory
Dual channel memory architecture. It has 1 x PCI-E x16, 2 x PCI-E x1 and 1 x PCI
slot. The board also sports 6 SATA II 3.0Gb/s slots with support of RAID
0,1,5,10 (Intel matrix storage technology). The board also incorporates a
Jmicron PATA/SATA controller, a LAN Atheros L1 PCI-E Gigabit LAN controller,
Realtek ALC 883, 8-channel High-Definition Audio. There is also support for 1394
using IEEE 1394 VIA VT6308P controller supports 2 x IEEE 1394a ports (one at
midboard; one at back panel).
Although P5E-VM HDMI is a mATX board, it does come
with a full featured BIOS for overclockers. Some other unique ASUS Features
supported include :
ASUS AI Lifestyle Features ASUS AI Lifestyle
Features:
- ASUS Splendid
ASUS Quiet Thermal Solution:
- ASUS AI Gear 2
- ASUS AI Nap
- ASUS Fanless Design
- ASUS Q-Fan 2
ASUS Crystal Sound:
- ASUS Noise Filter
ASUS EZ DIY:
- ASUS Q-Connector
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Special Features ASUS MyLogo 3
Overclocking Features Precision Tweaker 2:
- vDRAM: 33-step DRAM voltage control
- vChipset (N.B.): 24-step chipset voltage control
- vFSB: 16-step FSB voltage control
- vCPU PLL: 16-step CPU PLL voltage control
SFS (Stepless Frequency Selection)
- vCore: Adjustable CPU voltage at 0.0125V increment
- FSB tuning from 200MHz up to 800MHz at 1MHz increment
- Memory tuning from 533MHz up to 1333MHz
- PCI Express frequency tuning from 100MHz up to150MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
P5E-VM HDMI Specifications
Enjoy Full HD 1080p Multimedia Home-Theater Entertainment
- Support Intel® next generation 45nm Multi-core CPU
- Intel LGA775 Platform
- Intel® G35 chipset
- Onboard HDMI Connector
- Dual-channel DDR2 800/667/533 MHz
- Dual Display
- 12xUSB 2.0
- All High-quality Conductive Polymer Capacitors
