Introduction
If you were looking for
SATA2 based solutions, 775i915PL-SATA2 might just be the board for you. Based on
hte 915PL chipset, it supports the LGA775 P4 processors (non Dual Core) with the
conventional DDR400 modules. ASrock, "as it rocks"first introduced the Jmicron SATAII controller on this board.
Together with the already 4 SATA ports, you can now tap the power of SATA II by
connecting it to the SATA II interface.
On top of that, there are
two PCIe VGA slots for you to have surround view. Is SLI capable with a 16x+4x
combination? Check it out in the rest of the review. Below are the
specifications of the board.
CPU
- LGA775 for Intel Pentium 4 / Celeron D processor
- FSB 800/533 MHz
- Supports Hyper-Threading Technology
- Support EM64T CPU
- PCI Express x16 slot
- AGI Express slot (Default setting as PCI Express x 1, and can be adjusted
to PCI Express x4)
- PCI Express x1 slot
- PCI slot x4
VGA
- n/a
Audio
- Realtek ALC850 8 channel AC'97 audio codec
LAN
- Realtek RTL8101L 10/100 Fast Ethernet controller
- 802.3u, WOL supported
Connector
- 4 x Serial ATA 1.5Gb/s connectors
- 1 x ATA100/66 IDE connectors ( supports 2 x IDE devices)
- 1 x Floppy connector
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD audio in header
- Front panel audio connector
- 2 x USB 2.0 header (to support 4 USB2.0 ports)
Rear Panel
I/O
ASRock 8CH I/O Plus
- 4 x USB2.0 ports
- 1 x RJ45 LAN port
- 1 x Serial port (COM1)
- 1 x PS2 Keyboard connector
- 1 x PS2 Mouse connectors
- 1 x Parallel port (LPT1)
- 1 x 8 channel Audio port ( Line In/Out, Mic In)
